KioskGem Backlit LCD 1×5 Serial

KioskGem Backlit LCD 1×5 Serial

0

£352.00

Sensor : Tempered glass surface, Rated to 2 million signatures, High-performance E/M digitizer
Resolution & Conversion Rate : Exceeds industry standards, Programmable PPI
Signing Area : 4.4” x 1.3” | 112mm x 33mm

Topaz KioskGem Backlit LCD 1X5 Serial with Desk Mount is a ruggedized electronic signature pad with Serial data output for use in public-access or unsupervised kiosk environments. Durable tempered glass window protects the electronic screen, which displays ‘electronic ink’ under the pen tip in real-time as a user signs. The signature tablet bolts to housing with no exposed fasteners and the pen is tethered with a steel cable rated at 470lbs.

The signature tablet bolts to a housing with no exposed fasteners and the pen is tethered with a steel cable rated at 160 lbs.

SignatureGem® LCD 1×5 includes all the high-quality features of our electronic signature pad with the added feature of an LCD interactive display, allowing users to see “electronic ink” under the pen tip as they sign as well as navigate and display text and graphics. The wide signing area and rugged tempered glass signing surface make this a versatile pad for the most demanding applications.

The Backlit LCD model has a 1″ x 5″ transflective LCD screen with a bright backlight for improved viewing in any ambient lighting conditions.

*Signatures appear on the pad screen under-the-pen as the user signs. In addition, the LCD display can be used to display information to the user, and can also display on-screen buttons, hot-spots and checkboxes.

The “-B” model is a Serial device. It connects to a PC or Termial via an RS232 connection (pad has a female 9-pin connector – see image above). Typically less common than the USB connection, Serial is having somewhat of a comeback in the expanding Remote Access environment, being ideal for Citrix and/or Terminal services architecture.

This model has a three-year Manufacturer’s Warranty. However, even after this warranty period has passed (or if the repair is outside the terms of the warranty) we can offer a lifetime service to repair or refurbish the unit (if possible) for a modest charge.

Technical Data

Warranty3-years, with renewal option
SensorTempered glass surface, Rated to 2 million signatures, High-performance E/M digitizer
PenActive energized pen
Resolution & Conversion RateExceeds industry standards, Programmable PPI
Dimensions6.0” x 3.8” x 0.7” | 152mm x 97mm x 18mm
Signing Area4.4” x 1.3” | 112mm x 33mm
Unit Weight280g
Boxed Weight620g
Box Dimensions235x 165x 70mm
Authentication CapabilityForensic quality .SIG data capable of examination and authentication with our software
Dimensions152 × 97 × 18 mm
